Apé Auto Classic 435 cc diesel
Apé Auto Classic
Apé Auto Classic
| PARAMETER | |
|---|---|
| Fuel Type | Diesel |
| ENGINE | |
| Engine Type | Single Cylinder, Forced Air Cooled, DI Diesel BSVI Engine |
| Displacement | 435cc |
| Max Power | 5.7kW (7.64 hp) @3600rpm |
| Max Torque | 19Nm @2200rpm |
| TRANSMISSION | |
| Clutch Type | Multi Disc Wet Type |
| Gear Box | Constant Mesh |
| Gears | 4 forward , 1 Reverse |
| SUSPENSION | |
| Front | Hydraulic Telescopic Shock Absorber with Helical Compression Spring with dampener |
| Rear | Hydraulic Telescopic Shock Absorber with Rubber Compression Spring with dampener |
| Steering | Handle Bar Type |
| Brake | Drum Brake Hydraulic Actuated Internal Expanding Shoe Type |
| Tyre | 4.50 – 10, 8 PR |
| ELECTRICAL SYSTEM | |
| System Voltage | 12V DC |
| Battery Rating | 50 Ah |
| DIMENSIONS | |
| Wheelbase | 1920 mm |
| Overall Width | 1470 mm |
| Overall Length | 2940 mm |
| Overall Height | 1950 mm |
| Minimum Ground Clearance | 220 mm |
| WEIGHT | |
| Kerb Weight | 463 kg |
| GVW | 763 kg |
| Seating Capacity | Driver + 3 |
| PERFORMANCE | |
| Maximum Gradeability | 26.80% |
| Fuel Tank Capacity | 10.5 L |
| Maximum Speed | 55km/h |
